What Is Ambient Occlusion in Video Games?

In the intricate and captivating world of video games, every detail contributes to the immersion and engagement of the player. As we navigate through fantastical realms or hyper-realistic simulations, it’s easy to overlook the complex mechanisms at work behind the scenes that make our experience so compelling. One such subtle yet powerful mechanism is Ambient Occlusion, a technique responsible for making the visuals in our games stunningly lifelike.

Whether you’re a game developer, an avid gamer, or simply curious about the tech behind our virtual adventures, understanding Ambient Occlusion can add a new layer of appreciation to your gaming experiences.

In this article, we delve into the nuances of Ambient Occlusion, exploring how it works, its role in gaming, and the ways developers use and manipulate it to enhance our virtual escapades.

Understanding Ambient Occlusion

Credits: Dorian Iten

Ambient Occlusion (AO) is like a tool used in making video games and 3D animations. It helps figure out how much light should hit a certain spot, taking into account things that might block the light, like walls or other objects. The goal is to make the scene look more realistic, because in real life, not all places get the same amount of light – some areas are in shadow, while others are fully lit. So, AO helps to recreate this effect in the virtual world.

How Does Ambient Occlusion Work?

To understand how ambient occlusion works, we first need to understand its primary objective: to simulate the way light radiates in real life, especially off what we call “diffuse surfaces”, or those that reflect light in multiple directions.

AO achieves this through a process known as ray casting. This involves shooting rays from each point on a surface into the scene in a hemisphere above the point. Each ray tests for intersections with other geometry in the scene. The basic idea is that if a ray intersects with other geometry before reaching a certain distance, that ray is considered occluded.

The number of rays that are not occluded is then used to calculate the level of brightness for that point. If many rays are occluded, the point is in a tight space and should be shaded darker. Conversely, if few rays are occluded, the point is exposed to the environment and should be brighter.

In its simplest form, Ambient Occlusion is a ratio between the occluded rays and the total number of rays cast. This ratio is then used to darken the surface at that point, creating shadows that provide depth to the image.

Effects of Ambient Occlusion on Visibility

The implementation of Ambient Occlusion profoundly impacts the visibility of individual objects and the overall scene in a rendered image or animation.

Individual Objects: Ambient Occlusion can greatly enhance the level of detail visible in individual objects within a scene. By calculating how exposed each point of an object is to ambient light, AO allows the depiction of nuanced shadows and highlights that can accentuate the depth and volume of the objects, making them appear more three-dimensional.

Overall Scene: On a broader scale, Ambient Occlusion contributes to the overall mood and visual coherence of a scene. By darkening areas that are less exposed to ambient light, AO can create a sense of spatial relationship between objects, depth perception, and a sense of scale in a scene. This can make the scene as a whole look more believable and immersive, contributing to a more realistic visual experience.

Ambient Occlusion in Gaming

Ambient Occlusion in Gaming
Credits: Berkeley

In the world of video gaming, ambient occlusion (AO) plays a crucial role in enhancing the visual experience and creating a more immersive environment for players. Here, we’ll discuss its role, the balancing act between visual quality and computational demands, and the effect of toggling AO on and off in games.

Role of Ambient Occlusion in Gaming

AO serves to add depth and detail to the gaming environment. It creates soft shadows that ‘fill in’ the areas where direct light doesn’t reach, such as corners, crevices, or spaces between objects. By calculating how much ambient light (light that isn’t coming from a specific direction) can reach different parts of the game scene, AO enhances the perception of realism.

These shadows can give objects a more three-dimensional feel and enhance the overall realism of the scene. As a result, the gaming environment becomes more immersive and believable, enriching the gaming experience.

Trade-Off Between Visual Quality and Computational Demands

Implementing ambient occlusion in a game, however, isn’t without its challenges. The more realistic the graphics, the more computational power is required. In other words, to calculate the occlusion for every point in a scene and render those realistic shadows in real-time, a game would need to use more of your computer’s resources.

This can potentially slow down the game’s performance, especially on lower-end systems. It’s a balancing act that game developers constantly grapple with – improving visual quality without hampering the game’s performance and maintaining a smooth, enjoyable experience for players.

Turning Ambient Occlusion On and Off

Most modern video games allow players to customize their graphics settings, and turning AO on or off is typically one of these options.

When ambient occlusion is turned on, the game’s visual depth and realism are enhanced, making the scenes look more lifelike. You’ll notice more nuanced shadows, particularly in corners and places where objects meet, making them pop out and appear more three-dimensional.

On the flip side, turning off ambient occlusion might make the game look flatter and less realistic, as the subtle shadowing effects in the nooks and crannies are lost. However, this can be beneficial for less powerful systems or for players who prioritize performance over graphics. By turning off AO, the game requires less computational power and may run smoother, with fewer lags or stutters.

Check out the detailed GPU Performance List by PC Guide 101.

Tips for Setting Up Ambient Occlusion

Working with Ambient Occlusion (AO) in 3D applications requires a balance of settings to achieve realistic visuals while keeping rendering times efficient. Here are some tips to help you set up ambient occlusion in games and 3D animations.

Integrated Ambient Occlusion Settings

Many 3D software applications have built-in Ambient Occlusion settings. These tools allow artists and developers to generate AO effects within the application itself, without the need for additional plugins or software.

Before investing time in setting up a separate render pass for Ambient Occlusion, it’s advisable to check if your design material or software already has integrated AO settings. Leveraging these built-in tools can simplify your workflow and ensure consistency across the design process.

Baking Out the Ambient Occlusion Pass

One of the significant challenges in using AO is the time it can take to render, especially in animation where each frame of the animation requires rendering. To overcome this, you can use a method called “baking out” the Ambient Occlusion pass.

“Baking” refers to the process of calculating and storing the AO information in a texture map before the final rendering. This way, the computer doesn’t have to calculate AO in real-time, significantly speeding up the rendering process. Baking out is particularly beneficial in scenes that remain static, where the AO won’t change from one frame to the next.

Adjusting Max Distance

Sometimes, after generating the AO pass, you may find the shadows appear too deep or not deep enough. To adjust this, you can modify the ‘Max Distance’ in the AO settings.

The ‘Max Distance’ determines how far the rays, cast from a surface point to test occlusion, will travel to find intersecting geometry. A higher max distance means rays will travel further, potentially intersecting more objects, which can result in deeper and wider shadows. Conversely, a lower max distance means the rays travel a shorter distance, resulting in shallower and smaller shadows.

Directional Ambient Occlusion Pass

For an added level of realism, consider using a directional Ambient Occlusion pass. Unlike standard AO, which assumes that ambient light comes from all directions equally, directional AO considers the light’s position in the scene. This can add more directionality to the shadows, making them look more realistic and dynamic.

Directional AO helps the shadows to not only depend on the surrounding geometry but also on the direction of the primary light sources. This technique can greatly enhance the depth and realism of the scene, contributing to a more visually engaging and immersive experience.

Visit this article if your games are not using GPU. This will help you to increase the performance and quality of your gameplay.

Types of Ambient Occlusion

Types of Ambient Occlusion
Credits: WikiMedia

Ambient Occlusion (AO) has seen several iterations and improvements over the years, each with its unique approach to achieving more realistic lighting and shading. Let’s delve into the different types of AO techniques used in video games.

Screen Space Ambient Occlusion (SSAO)

Screen Space Ambient Occlusion (SSAO) is a popular AO technique used in real-time rendering, including video games. SSAO operates exclusively within the screen space, meaning it only considers the depth information of pixels that are visible on the screen.

SSAO generates a depth map for the current frame and then approximates the amount of occlusion for each pixel by comparing its depth value to the depth values of nearby pixels. It’s a fast and efficient method, but it can sometimes lead to inaccuracies as it lacks the broader scene context beyond the current frame.

Horizon-Based Ambient Occlusion (HBAO)

Horizon-Based Ambient Occlusion (HBAO) is an advanced form of SSAO. While SSAO can sometimes produce halos around objects due to its limited perspective, HBAO uses more sophisticated algorithms to reduce these artifacts and produce a more accurate and realistic occlusion effect.

HBAO considers the “horizon angle” at each pixel to calculate occlusion, leading to more realistic shadowing at the edges of objects and between adjacent surfaces.

High-Definition Ambient Occlusion (HDAO)

High-Definition Ambient Occlusion (HDAO) is another variant of SSAO, developed by AMD. The idea behind HDAO is to deliver a high-quality ambient occlusion solution that is also efficient in terms of performance.

HDAO differs from other techniques in the way it samples points for occlusion calculation. It employs a smart depth comparison technique that reduces over-occlusion in areas close to the camera, thus producing a higher quality result.

Screen Space Directional Occlusion (SSDO)

Screen Space Directional Occlusion (SSDO) is an improvement over SSAO that adds directional information to the occlusion calculation. This makes it possible to create shadows that are not only influenced by objects blocking ambient light but also take into account the direction of the primary light sources.

SSDO can produce more detailed and realistic shadows, but it requires more computational resources, making it a bit heavier for real-time rendering.

Voxel Ambient Occlusion (VXAO)

Voxel Ambient Occlusion (VXAO) is a relatively new AO technique developed by Nvidia. Instead of operating in screen space like SSAO, HBAO, HDAO, and SSDO, VXAO operates in the actual 3D space of the game world.

VXAO first voxelizes the 3D scene, turning it into a 3D grid of “voxels” (similar to 3D pixels), then calculates occlusion based on this voxel representation. This allows VXAO to produce highly accurate occlusion effects, with deep, wide shadows that correctly reflect the geometry of the scene. However, VXAO is significantly more performance-intensive than other AO techniques.

Frequently Asked Questions

Here are some frequently asked questions about ambient occlusion in video games:

Does ambient occlusion affect FPS?

Yes, Ambient Occlusion can affect the Frames Per Second (FPS) in video games. The more complex AO techniques require additional computational resources, which can lower the FPS, particularly on less powerful systems. It’s often a trade-off between visual quality and game performance.

What is the best ambient occlusion?

The “best” Ambient Occlusion technique depends on the specific requirements of a game and the capabilities of the hardware running it. For higher-end systems, Voxel Ambient Occlusion (VXAO) can offer the most accurate and realistic effects. However, on less powerful systems or for games that need to balance performance and visuals, techniques like Screen Space Ambient Occlusion (SSAO) or Horizon-Based Ambient Occlusion (HBAO) might be more appropriate.


Ambient Occlusion is a key element in enhancing the visual realism of video games. As graphics technology continues to evolve, the implementation and influence of ambient occlusion will undoubtedly progress. The nuanced application of AO can be a game-changer in defining a game’s visual quality and player immersion.

With the ongoing advancements in graphics and gaming technology, the future of ambient occlusion appears bright and filled with potential. As the game development community continues to push the boundaries of what’s possible, AO will undoubtedly continue to play a vital role in the quest for increasingly realistic virtual worlds.
